Beneath Every Brilliant Floor: The Full Story of Mr. JO Eco Underlay

When it comes to epoxy floors, what meets the eye — smooth, glossy, seamless finishes — is only half the story. The other half is hidden below, quietly doing the heavy lifting. That hidden layer is the underlay, and it’s where long-term durability, strength, and finish quality are truly built.

MR. JO Eco Underlay is not just a filler — it’s a foundation, a problem solver, and a performance enhancer designed for today’s high-demand flooring systems.

🧩 The Challenge at Many Sites

Waterproofing failures often stem from an unexpected source: the water added during mixing. On-site dilution with hard water, unmeasured quantities, or inconsistent mixing can compromise the final film.

Even the best epoxy systems can falter if a careless mix leads to chalky coatings, patchy curing, or poor bonding. Especially in large projects, controlling field variables becomes a challenge.

🟢 Why Use an Underlay?

For epoxy flooring systems of 2 mm and above, an underlay serves multiple functions:

• Corrects surface irregularities and levels the substrate
• Builds strength and thickness cost-effectively
• Prepares the floor for smoother, more uniform topcoat application
• Reveals surface defects early for rectification before finishing
• Reduces topcoat consumption and improves adhesion

Think of it as the leveling course in road construction — it doesn’t shine, but the final ride depends entirely on it.

⚡ Meet the Eco Underlay Family

The MR. JO Eco Underlay system is available in three specialized versions — each suited to a different application need:

1. Eco Underlay – iFLO (Flowable Screed)

A highly flowable screed version for easier spreading and better self-leveling. Ideal when you need quick coverage with minimal troweling effort.

• Packaging:  (5 + 2.5 + 12.5)
• Mix Ratio (A:B:C): 100:50:250
• Application: Poured and leveled with notched rake and spiked roller
• Recommended for:
  • Large, open industrial floors
  • Light undulations or minor unevenness
  • Quick base preparation for epoxy overlays







1. Surface Preparation
   – Mechanically grind or shot blast to remove laitance and dust
   – Ensure the surface is dry, clean, and oil-free
   – Concrete substrate should be at least 25 MPa
2. Priming
   – Use MR. JO Eco Primer, UPS, LVC, or MVC depending on substrate condition
3. Mixing
   – Combine Part A and B thoroughly
   – Slowly add Part C (aggregates) until homogeneous
   – Use mechanical mixing for consistency
4. Application
   – For flowable versions: pour and spread with a rake, then roll with spiked roller
   – For tampable: lay with trowel and compact evenly
5. Curing

– Walkable in ~24 hours at 25°C
– Full cure in 7 days
– Topcoat can be applied after 24–36 hours

⚠️ Tips & Precautions

• Do not apply if substrate temperature is below 15°C
• Stick to recommended mix ratios — overloading filler will weaken bonding
• Ensure proper de-aeration with spike roller for flowable grades
• Protect freshly laid underlay from dust, foot traffic, and moisture
• Always verify substrate moisture levels if using on damp concrete.

💡 Why Choose MR. JO Eco Underlay?

✔️ Optimized for fast turnaround projects
✔️ Seamless integration with all MR. JO flooring and coating systems
✔️Flexible options for flowable or tampable applications
✔️Cost-effective bulk layer to reduce topcoat costs
✔️ Available in job-friendly pack sizes

Whether you’re building a new industrial floor or upgrading an old one, the Eco Underlay series helps you lay a smart, strong, and smooth foundation — so your epoxy floor can shine brighter and last longer.
