Seamless Strength – The Flowable Screed That Builds the Backbone of Great Epoxy Floors
Every great floor begins with a strong, level foundation — and MR. JO Underlay-FLO is built exactly for that. This flowable epoxy underlay system is engineered to deliver dense, seamless, and smooth screeds that provide a high-performance base for epoxy topcoats across industrial, commercial, and high-traffic floors.
Ideal for 2 mm and thicker epoxy systems, FLO ensures that your finished floor looks sharp, lasts long, and performs under pressure.
🌊 What Makes FLO Special?
- Flowable formulation – Easy to pour, spread, and level
- High filler compatibility – Optimized for quartz sand loading without loss of workability
- Excellent substrate bonding – Uses a low-viscosity bonding system underneath
- Crack-covering & floor-correcting – Smooths undulations and fills microcracks before topcoat
- Flexible underlay choice – Compatible with Floor-SL, CRSL, EcoFloor, Protectokot & Floorkot ranges
📦 Composition & Mixing
Recommended Mixing Ratio (by weight):
- Resin (Part A): 5 kg
- Hardener (Part B): 2.5 kg
- Quartz Sand (Part C): 12.5 kg
→ Total batch weight: 20 kg
Pack Sizes:
- 7.5 kg (5 + 2.5) – Resin + Hardener
- 12.5 kg – Quartz Sand (sold separately or site-sourced)
This mix offers consistent flowability, yet builds strong enough mass to support high-load topcoats.
🧱 Where to Use FLO
- As an intermediate epoxy layer below 2 mm SL systems
- To even out rough concrete or mortar beds
- As a leveling screed for epoxy systems over large areas
- Substrate base for Protectokot or Floorkot systems in process areas
- In warehouses, showrooms, pharma, auto units, and ESD-sensitive zones
⚙️ Performance Advantages
✅ Flowable Consistency – Easy to lay and finish with standard tools
✅ Superior Workability – Sufficient open time for large area spreading
✅ Dust-free & Seamless – Minimizes air entrapment and trowel marks
✅ Strong Intercoat Bonding – Excellent hold with MR. JO Primers and Topcoats
✅ Cost-Efficient Base – Reduces resin-rich topcoat usage, cuts flooring cost
🛠️ Application Process
- Surface Preparation
- Shot-blasting or mechanical grinding
- Ensure dust, oil, laitance, and moisture are removed
- Prime using MR. JO Primer-LVC or MVC for dry substrates, or UPS for damp substrates
- Mixing
- Add Part B (hardener) to Part A (resin) and mix for 2 minutes
- Slowly add Part C (filler) while mixing to get a uniform, flowable mix
- Use mechanical stirrer at slow speed
- Laying the Screed
- Pour material on the floor and spread with rake/trowel
- Use spike roller to remove trapped air
- Target thickness: 2–4 mm
- Open to topcoat after 12–24 hours
🧩 Pairing Recommendations
- For Topcoats: Use with Mr. JO Floor-SL0.5, SL1, SL2 or EcoFloor range
- For Chemical Areas: Under MR. JO Protectokot-CR/CRH/CSA coatings
- For Heavy Loads: Follow with epoxy screed topping or MR. JO Floorkot-HB
- For Smooth Finish: Apply SL topcoat within 24–48 hours of screed cure
⚠️ Precautions
- Do not apply below 15°C surface temperature
- Ensure correct primer selection and proper curing between layers
- Always use calibrated quartz sand (0.1–0.5 mm) for best flow and finish
- Avoid water exposure for first 48 hours
- Protect laid surface from dust and contaminants during curing
💡 Why Choose MR. JO Underlay FLO?
🌟 Factory-controlled quality
🔄Versatile compatibility
🧱Excellent load-spreading
🪄Smooth finish foundation
💪Hard-wearing, ready for anything
MR. JO Underlay-FLO is the invisible layer that powers visible excellence. Behind every flawless epoxy floor, there’s a FLO screed doing the heavy lifting.
